Shackle plate tata ace, intra | Leaf Spring Link Plate Export

Export-Grade Shackle plate, tata ace, intra for Commercial Logistics Fleets

In light commercial transport fleets like the Tata Ace and Tata Intra series operating under demanding load conditions across unpaved rural tracks and urban corridors in South Asia, Nepal, Africa, and the Middle East, maintaining structural integrity in the leaf spring suspension is essential for vehicle stability and axle safety. The Shackle plate, tata ace, intra acts as the crucial pivoting link that connects the leaf spring eyes to the chassis frame hanger brackets, allowing the leaf spring main blade to expand and contract smoothly as the vehicle travels over uneven ground. Carrying continuous commercial overloads subjects these shackle plates to intense tensile and lateral shearing forces. Standard or worn shackle plates often develop elongated, ovalized pin holes, bend sideways, or crack around the bolt passages. A damaged or worn Shackle plate, tata ace, intra leads to severe operational hazards—including uneven ride height, chassis tilt, severe tire tread wear, unstable load handling during turns, and dangerous suspension clunking noises. Upgrading to our export-quality Shackle plate, tata ace, intra guarantees rigid leaf spring support and long-term durability under maximum GVW.

Manufactured using thick-gauge, cold-rolled structural steel, this shackle link plate is press-formed to resist bending and lateral twist. The pin mounting holes are CNC-punched to exact tolerances to ensure a snug, wobble-free fit around shackle pins and rubber bushings.

Key Features & Technical Benefits of Tata Ace & Intra Shackle Plate:

• Heavy-Gauge Stamped Structural Steel: Engineered to resist bending, twisting, and structural fatigue under heavy commercial payload shocks.

• Precision CNC-Punched Pin Bores: Clean, exact-fit hole alignment prevents shackle pin looseness and uneven bushing wear.

• Corrosion-Resistant Protective Finish: Treated with an anti-rust black E-coat or zinc passivated layer to endure mud, road spray, and harsh climates.

• Multi-Country OES Standard Fitment: Stamped strictly according to original Tata Motors factory dimensions for Tata Ace, Ace Gold, Ace Zip, Intra V10, V20, and V30 platforms.

Technical Specifications:

Attribute	Specification
Product Name	Leaf Spring Shackle Link Plate / Suspension Hanger Bracket Plate
Compatible Platforms	Tata Ace, Ace Gold, Ace Zip, Ace Mega, Intra V10, V20, V30, V50 & Export Variants
System Classification	Suspension System / Leaf Spring & Shackle Mounting Hardware
Material Base	High-Tensile Heavy-Gauge Stamped Structural Carbon Steel
Surface Finish	Anti-Rust Protective Black Coating / Zinc Passivated
Export Availability	Ready Stock for Wholesale Export (South Asia, Africa, Middle East)
Fitment Classification	Direct OES Standard Replacement Component

Professional Installation & Suspension Servicing Guidelines

• Replace Shackle Pins & Bushings Simultaneously: When installing a new Shackle plate, tata ace, intra, always inspect and replace worn shackle pins and rubber/polyurethane spring bushings. Re-using worn pins inside a new plate will lead to rapid hole ovalization and noisy suspension play.

• Torque Lock Nuts to Factory Specifications: Tighten the shackle pin nuts evenly across both side plates. Avoid over-tightening to allow smooth pivoting motion of the leaf spring end during suspension compression.
